VoltDRAM
VoltDRAM
We are a leading manufacturer specializing in high-density multilayer printed circuit boards and specialty boards. With certifications including UL, ISO9001:2015, ISO14001:2015, CQC, IATF16949:2016, and "National Military Standard," we provide top-quality products and services.
Our extensive product range includes multilayer boards, impedance boards, high-frequency boards, high TG thick copper foil boards, 5G high-speed boards, buried blind via boards, aluminum-based boards, hybrid dielectric boards, HDI, rigid-flex boards, specialty boards, and customized solutions.
Driven by technological innovation, our products are widely used in industries such as communication equipment, industrial control, automotive electronics, energy and power, medical devices, IoT, research institutions, aerospace, and defense. With over 19 years of experience, we have served over 1,000 technology innovation-oriented enterprises with rapid prototyping and mass production services. We are committed to delivering cutting-edge solutions and exceeding customer expectations in the dynamic electronics industry.
| Rigid PCB Manufacturing Capability | ||
|---|---|---|
| Category | Volume Production | Sample Processing |
| Layer Count | 1-68L | 64 Layer |
| Max Thickness | 10mm (394mil) | 14mm (551mil) |
| Min Line Width / Space (Inner) | 2.2mil / 2.2mil | 2.0mil / 2.0mil |
| Min Line Width / Space (Outer) | 2.5mil / 2.5mil | 2.2mil / 2.2mil |
| Alignment Capability (with Core) | ±25um | ±20um |
| Alignment Capability (Inner Layer) | ±5mil | ±4mil |
| Max Copper Weight | 6oz | 30oz |
| Hole Size (Mechanical) | ≥0.15mm (6mil) | ≥0.1mm (4mil) |
| Hole Size (Laser) | 0.1mm (4mil) | 0.050mm (2mil) |
| Max Size (Unit) | 850mm x 570mm | 1000mm x 600mm |
| Max Size (Panel) | 1250mm x 570mm | 1320mm x 600mm |
| Aspect Ratio (Unit) | 20:1 | 28:1 |
| Aspect Ratio (Panel) | 25:1 | 35:1 |
| Lead-free / Halogen-free Material | EM827, 370HR, S1000-2, IT180A, EM825, IT158, S1000 / S1155, R1566W, EM285, TU862HF | |
| High-speed PCB Material | Megtron6, Megtron4, Megtron7, TU872SLK, FR408HR, N4000-13 Series, MW4000, MW2000, TU933 | |
| High-frequency PCB Material | Ro3003, Ro3006, Ro4350B, Ro4360G2, Ro4835, CLTE, Genclad, RF35, FastRise27 | |
| Others | Polyimide, Tk, LCP, BT, C-ply, Fradflex, Omega, ZBC2000 | |
| Surface Finished | HAL, HAL-LF, ENIG, IMMERSION TIN, OSP, IMMERSION SILIVER, GOLD FINGER, Hard Gold / Soft Gold Plating | |
| Special Technology | Blind & buried holes, Via in pad, Semi-plating holes, Counterbore, Step mounting holes, drill Mixed RF PCB, Busbar PCB | |
Actual conditions are subject to final confirmation.
As PCBs are customized products, standard returns are not supported. For verified quality issues, please get in touch with us for a refund or replacement. Please note we do not cover additional losses or costs beyond the value of the product itself. Delays in delivery due to force majeure factors (such as power outages or water supply interruptions) are not eligible for compensation.
If there are any issues or special instructions, please communicate directly with our team for confirmation. Do not leave independent messages, as we cannot guarantee they will be seen. Before and after payment, please confirm the process specifications, quantity, and layers. Once the order proceeds to production or shipping, refunds are not available. Since PCBs require high expertise, please consult your engineer or our support team if details are unclear.
Orders placed before 17:00 are recorded on the same day; orders placed after 17:00 are recorded the next business day. "24-hour delivery" represents one working day, not literally 24 chronological hours. Delivery schedules do not include Sundays or public holidays.
Green solder mask, white silkscreen, 1.6mm board thickness, HASL surface finish, 1oz copper thickness, vias with solder mask, line width/spacing ≥ 0.2mm, and via diameters above 0.3mm. Gerber formats are matched to the provided files. Standard pricing is based on these processes. Please inform us of any special process requirements for a custom quote.
| Layer Count | Sample Shortest Lead Time | Sample Standard Lead Time | Mass Production Lead Time |
|---|---|---|---|
| 2 Layers | 24 h | 3 days | 6-7 days |
| 4 Layers | 36 h | 5 days | 8-10 days |
| 6 Layers | 48 h | 5 days | 8-12 days |
| 8 Layers | 72 h | 5 days | 9-12 days |
| 10 Layers | 4 days | 7 days | 14 days |
| 12 Layers | 4 days | 7 days | 16 days |
| 14 Layers | 5 days | 8 days | 16 days |
| 16 Layers | 5 days | 9 days | 18 days |
| 18 Layers | 7 days | 10 days | 18 days |
| 20 Layers & Above | To be negotiated | To be negotiated | To be negotiated |
