We have invested in the best equipment, environment and staff training. We have a production capability for standard and HDI, Rigid, RF and high frequency PCBs, together with through hole and min 0201 chips, 0.2mm pitch BGA balls SMD soldering, in small batch, mid volume and high volume quantities.
Professional PCB electronics manufacture services, every PCB enquiry or order is handled in the strictest of confidence. We can fabricate Laser holes, Impedance Control PCB, Buried & Blind Holes PCB, Countersunk hole, and other special material or special process PCBs.
| Items | Capacity |
|---|---|
| 1. Base Material | Roger 4000+ FR4 Mixed pressure |
| 2. Layer / PCB thickness | 6 Layer / 1.6mm |
| 3. Copper thickness | 1oz copper |
| 4. Solder mask / Silkscreen | green solder mask / white silkscreen |
| 5. Surface finished | immersion gold |
| 6. Min width/space | 4.5 / 3.5 mil |
| 7. Min holes | 0.2mm |
| 8. Technics Characteristic | trace width ± 10 % |
| 9. Technical Requirement | process difficulty: Roger 4000+ FR4 Mixed pressure, IPC class II standard. |
| Standard Produce time | 9-12 days |
| Fast produce time | 24h ~ 90h |
| Payment and shipment |
1) By T/T bank (wire transfer, the most popular way) 2) By Western Union 3) By Paypal (especially for samples) 4) By Cash |
We have established a quality system with ISO9001 and strictly implement the IPC class III standard to inspect the quality. 100% inspection includes electric test and AOI inspection. It can carry out high voltage test, impedance test, microsection, weldability test and other professional tests to keep up with more demands from users of high-tech products.
We have been manufacturing printed circuit boards for more than 20 years. Established in 1990, as a PCB manufacture supplier of world competitive, high tolerance, high quality, small to medium volume production quantities. Whether it is a prototype printed circuit board assembly or large volume PCB production, we have the capacity and the knowledge to satisfy all of your printed circuit board production requirements.
We pride ourselves on a professional service with a friendly approach where quality is of paramount importance, in accordance with our ISO9001 Quality Management system and UL Approval.
We specialize in Printed Circuit Board Manufacturing and Quick turn PCB Prototype Fabrication. We specialize in Quick turn PCB services with an industry leading turnaround time as fast as 24 hours. When your company needs fast and rapid PCB prototyping, you can count on custom circuit boards to deliver high quality printed circuit boards on time with competitive pricing.
We encourage all prospective clients to pay us a visit, we offer an open door policy for all customers both new and old, and believe that once you’ve seen our facility and talked to our expert staff you’ll have no doubts over our ability to meet your individual needs. We look forward to working with you to produce high quality PCBs at a competitive price.
We have over 15 professional engineers, and all the products are tested successfully before warehousing and shipping.
We always keep a large stock of products. When you need to purchase or repair parts, it is our pleasure to serve you. We look forward to building a good business relationship.
We not only strive to deliver quality products to our customers, but we also place great importance on offering a complete and secure packaging setup. We provide personalized packaging options for all orders.
Common packaging:
Customized Cartons:
Outer cartons can be customized and printed with details such as customer-specified address markings, destination labels, and other necessary shipment parameters according to customer requirements.
We provide one-stop PCB/PCBA customization services. To meet all of customer's PCB/PCBA requirements is our primary goal.
To deliver top quality PCB/PCBA to our customers, we conduct multiple tests to ensure overall reliability before shipment:
Q1:How can you guarantee the quality of the parts?
A: We offer a 3-month warranty for used parts and a 1-year warranty for new parts. If you receive components that do not function properly, you may return them to us within 7 days, and we will cover the return shipping costs.
Q2:How are the items packaged when sent out?
A: We typically use 3cm thick foam board lining within shipping boxes to protect all components. Standard shipping cartons are used, and customized wooden boxes can be manufactured for heavier components.
Q3:Which payment methods and express couriers do you accept?
A: We support diverse payment options and delivery companies. Our standard terms accept Paypal, Western Union, and T/T Bank Transfers. Delivery options include UPS, EMS, TNT, FEDEX, DHL, and more.
Q4:Do you have testing equipment, and what is your typical delivery time?
A: We utilize advanced testing equipment, ensuring that all components undergo 100% testing verification before shipping out. Since we maintain substantial stock, standard delivery time is usually 1-2 days.
Q5:If I only have a physical PCB sample but no file, can you fabricate it for me? Can you generate a Gerber file?
A: Yes, we can trace and copy the layout designs from your physical samples to generate a standardized Gerber file for manufacturing. We can also develop schematics and generate corresponding Gerber designs as required.
Q6:Are my design files kept secure when submitted for production?
A: Absolutely. All client files are held in strict confidentiality within our production facilities and are protected from third-party access. We are prepared to sign mutual Non-Disclosure Agreements (NDA) for added security.
